Gs Audio Full-Range Amplifier GS-200.4 SQ – 4*200Wrms @2ohm

Gs Audio Amplifier GS-200.4 SQ / 4*200Wrms @2ohm / 2*400wRMS @4ohmThe new Gs Audio Full Range line of amplifiers for everyday use is designed and customized to provide the best sound qualities with a quality level similar to a class AB but mdimensions as compact as a class D. Due precisely to the sound qualities, a smaller size than a common class AB, and the versatility of a full range amplifier we named this series SQ (Sound quality). As you can see from the internal photos these amplifiers made in Korea have nothing to do with modern Brazilian digital, but they are characterized by a large chassis, large capacitors and toroids, as well as a power terminal block for cables up to 25mmq! In addition, thanks to the clipping indicator light, it will be very easy to do-it-yourself calibration of the maximum operating level before the clip threshold Powers: 4*140Wrms @ 4 ohms4*200Wrms @ 2 ohmsbridge mode: 2*400Wrms @ 4 ohmstrimode: 2*140Wrms @4 ohm + 1*400Wrms @ 4 ohm For those using the amplifier with internal active filters without a processor, here are the frequency cutoffs:separate for channels 1-2 and 3-4LPF: 50hz to 500Hz (can be turned off)HPF: 50hz to 1200Hz (can be turned off) Bass boost controller:0-12dB The amplifier comes complete with screws, allen wrenches, stickers. The installation manual is not included in the box but can be downloaded at the links below Price refers to 1 amplifier with 1 remote controlFor any other info not found in the data sheet, please remember our direct whatsapp contact +39 3473263458CE marked amplifiersDownload here the complete multilingual user and maintenance manualDownload here the multilingual CE marking certificateDownload here the product data sheet
